RESEARCH ARTICLE


Research of Amoxicillin Microcapsules Preparation Playing Micro-Jetting Technology



Huaiyuan Sun 1, 2, *, Qingqing Gu 1, Yuehua Liao 2, Chenjie Sun 1
1 College of Medical Instrument and Food Engineering, University of Shanghai for Science and Technology, Shanghai, 200093, China
2 Shanghai Medical Instrumentation College, Shanghai, 200093, China


Article Metrics

CrossRef Citations:
1
Total Statistics:

Full-Text HTML Views: 560
Abstract HTML Views: 451
PDF Downloads: 202
Total Views/Downloads: 1213
Unique Statistics:

Full-Text HTML Views: 326
Abstract HTML Views: 292
PDF Downloads: 180
Total Views/Downloads: 798



Creative Commons License
© Sun et al.; Licensee Bentham Open.

open-access license: This is an open access article licensed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/3.0/) which permits unrestricted, non-commercial use, distribution and reproduction in any medium, provided the work is properly cited.

* Address correspondence to this author at the No. 334 JungongRoad, Shanghai, China. Postcode: 200093; Tel: 18301781791; E-mail: shy62123@163.com


Abstract

With polylactic-co-glycolic acid(PLGA) as shell material of microcapsule, amoxicillin as the model, poly(vinyl alcohol) and twain as surfactant, amoxicillin-PLGA microcapsules were manufactured using digital micro-jetting technology and a glass nozzle of 40μm diameter. The influences of the parameters of micro-jetting system on the mean grain size and size distribution of amoxicillin-PLGA microcapsules were studied with single factor analysis and orthogonal experiment method, namely, PLGA solution concentration, driving voltage, jetting frequency, stirrer speed, etc. The optimal result was obtained; the form representation of microcapsule was analyzed as well. The results show that, under certain conditions of experimental drug prescription, driving voltage was proportional to the particle size; jetting frequency and stirrer speed were inversely proportional. When the PLGA concentration for 3%, driving voltage for 80V, the jetting frequency for 10000Hz and the stirrer speed for 750rpm, the particles were in an ideal state with the mean grain size of 60.246μm, the encapsulation efficiency reached 62.39% and 2.1% for drug loading.

Keywords: Micro-jetting, Amoxicillin, PLGA, Microcapsule preparation.
